Bilstein MDS - Motorsports



Modular Damping System (MDS)

Double adjustable aluminum body coilover shocks and struts designed for those seeking the very best racing damper for endurance or sprint racing. Found on the top teams in the Tudor United Sportscar Championship down to club level racing.



The product benefits at a glance:

  • Monotube gas pressure construction

  • Aluminum body construction reduces weight & improves cooling

  • Independent 10-way rebound and compression adjustable shaft

  • 1:1 billet linear o-ring backed 46mm piston

  • Application specific design for many popular road race and cup class vehicles







Wright Motorsports uses Bilstein MDS shocks on their #58 Porsche running in the Tudor United SportsCar Championship.

Bilstein Clubsport



BILSTEIN Clubsport®

Racing and road driving united

The BILSTEIN Clubsport® suspension system is a fully street-legal, TÜV-certified high-end coilover package that is also designed for uncompromising use in the fields of racing and clubsport. This kit combines the tried-and-tested BILSTEIN mono-tube gas pressure technology with the highest levels of engineering from the field of motor sport.



The 2-way adjustable suspension system, complete with integrated reservoir, provides a significant weight advantage for racing and clubsport use compared to systems with external reservoirs. Rebound and compression forces can be adjusted independently via the two easily accessible motorsport-proven aluminum adjustment dials inside the vehicle, enabling the suspension setup to be changed quickly and accurately at all times.



With 10 click positions for rebound and 10 click positions for compression, a wide range of handling options can be selected in just seconds, allowing for instant back-to-back set-up modification and testing. The combination of adjustable wheel camber and ride height with the 100 possible valving settings, make it possible to fine-tune the suspension setup based on the specific racetrack, weather conditions and vehicle weight, as well as driver and tire specifications.



Product Benefits:

  • 2-way damping force adjuster for independent adjustment of rebound and compression forces

  • Aluminum adjustment wheels with clearly identified tuning settings from 1 (soft) to 10 (hard)

  • Color-coding: red for rebound force, blue for compression force

  • Manually adjustable without additional tools

  • Each definite click of the wheel confirms the simple and quick damping force adjustment

  • Wheel camber is adjustable by aluminum support bearing

  • Weight advantage by eliminating the need for an external oil reservoir

  • BILSTEIN-monotube technology developed through years of motorsport involvement

  • Spring plates and lock nuts made from special aluminium alloy

  • Quality built racing springs

  • Surface coating using Triple-C-Technology® for long-lasting corrosion resistance

Bilstein PSS9/10



The manually adjustable damping mono-tube gas shock absorbers feature 9 or 10-stage precise compression and rebound settings, from comfort to competition. The threaded body allows accurate adjustability of the front and rear progressive rate springs to achieve the vehicle ride height, center of gravity and level of performance handling desired.



The Bilstein B16 system puts you in complete control, providing the kind of precise suspension tuning formerly available only on race cars. From a weekend of competition to daily driving, this system provides perfect handling performance for every situation.



The product benefits at a glance:



Individual settings ranging from maximum Comfort to aggressive Sport can be selected by the twist of a dial (9 on PSS9, 10 on PSS10)

  • Threaded body adjustable range of 20 mm at both axles

  • Lowering of approx. 30-50 mm at front and rear

  • Road-tested and fine-tuned by BILSTEIN ride engineers, under extreme motorsports conditions

  • Spring plates and lock nuts made from a special aluminum alloy

  • Surface coating using Triple-C-Technology®for long-lasting corrosion resistance

  • Round threads for easy adjustment

  • Quality sport springs made from highly durable material

  • Quality sport springs made from highly durable material

  • Gas pressure technology

  • BILSTEIN monotube technology, made in Germany

Bilstein Damptronic



The product benefits at a glance:



  • Retains your factory SPORT button function allowing 2 suspension modes

  • Electronic adjustment system developed specifically for each application

  • Adjustable setting levels for the most dynamic driving experieneAbility to switch instantly between settings to suit driving conditions

  • Threaded body adjustable range of 20 mm at both axels, while installed

  • Lowering of approx. 30-50 mm at front and rear

  • Road-tested and fine-tuned by BILSTEIN ride engineers, under extreme motorsports conditions

  • Spring plates and lock nuts made from a special aluminium alloy

  • Surface coating using Triple-C-Technology®for long-lasting corrosion resistance

  • Round threads for easy adjustment

  • Quality sport springs made from highly durable material

  • Gas pressure technology

  • BILSTEIN monotube technology, made in Germany
